Honeywell t410a wiring diagram 240v. If not main service panel. My problem is that the directions for the honeywell t410a b thermostat that i wa. Product data and specifications product data for t410a t410b electric heat thermostats. Ct410a b line voltage electric heat thermostats 69 1681efš1 2 2 remove old thermostat warning 120v to 240v line volt electrical shock hazard.

Symptom checkout action no heat. Can cause serious injury or death. Remove cover of old thermostatšcover. Honeywell honeywell limited honeywell limitøe 1985 douglas drive north 35 dynamic drive golden valley mn 55422 scarborough ontario m1v 4z9 t410a b electric heat thermostats fig.

Contains all the essential wiring diagrams across our range of heating controls. A ct410a only has two terminals making it easy to connect to your home wiring. Again referring to the honeywell thermostat ct31a1003 wiring diagram you can see it requires only two wires r and w. T410a b line voltage electric heat thermostats troubleshooting your honeywell thermostat requires little or no attention.

It doesn t control cooling and because it s a mechanical thermostat it doesn t need power for internal functions so it has no c wire. All wiring must comply with local. Ct410a b line voltage electric heat thermostats 2 remove old thermostat 3 wire and mount new thermostat warning remove thermostat cover by grasping the top 120v to 240v line volt electrical shock and bottom ends with your fingers and pulling hazard. Disconnect power supply to prevent electrical shock or equipment damage.

Check out our voltage blog pos. The wires are l1 and l2 t1 and t2. Mounting thermostat on outlet box. A bimetallic spring inside the honeywell ct410a thermostat reacts to changes in temperature turning your baseboard heater on and off.

Thomas with cadet tech support shows you how to install a double pole wall thermostat on a 240 volt electric baseboard heater. Installation materials line voltage electric heat thermostats. Click the icon or the document title to download the pdf. Make sure power is on at heater should start to warm up within two minutes.

Installation materials termostatos de calefaccion electrica de voltaje de linea spanish. Turn off power to the heating circuit at the main service panel before beginning installation. All four answered by a verified electrician. Most problems can generally be traced to the following.
